Home » Products » Drilling Rig Mud Circulation System » Drilling pump » Bearing » Cylindrical Roller Bearing NU2309E 32609E N2309E NF2309E NJ2309E NUP2309E

PRODUCT CATEGORY

Cylindrical Roller Bearing NU2309E 32609E N2309E NF2309E NJ2309E NUP2309E

Cylindrical Roller Bearing NU2309E 32609E N2309E NF2309E NJ2309E NUP2309E

Model:
all
Brand:
hebei yingpai
Code:
84139100


SKU:
Availability:



Inquire PDF Export

Product Description

Product Description

Cylindrical Roller Berings

In bearings of Cylindrical Roller Berings the cylindrical rollers are in linear contact with the raceways. They have a high radial load capacity and are suitable for high speeds.

Cylindrical roller bearings, in which either the inner or outer rings has two ribs and the other ring has one, are capable of taking some axial load in one direction Double-row cylindrical roller bearings have high radial rigidity and are used primarily for precision machine tools. Some cylindrical roller bearings have no ribs on either the inner or outer ring, so the rings can move axially relative to each other. These can be used as free-end bearings.

There are different types designated as NU, NJ, NUP, N, NF (for single-row cylindrical roller bearings), NNU, and NN (for double-row cylindrical roller bearings depending on the design or absence of side ribs). The outer and inner rings of all types are separable .

Cylindrical Roller Berings Sprecification

NU2309E 32609E N2309E NF2309E NJ2309E NUP2309E

45 100 36MM 1.34KG

Main items

Bearing NO.		(mm)			Bearing No.		(mm)
ITEM NO.	OLD ITEM	d	D	B	Item no.	Old item	d	D	B
N202	2202	15	35	11	NUP205	92205	25	52	15
NF202	12202	15	35	11	RN205	502205	25	-	15
NU202	32202	15	35	11	RNU205	292205	-	52	15
NJ202	42202	15	35	11	N2205	2505	25	52	18
RN202	502202	15	-	11	N2205	2505	25	52	18
RNU202	292202	-	35	11	NUP2205NV	E192505K	25	52	18
N203	2203	17	40	12	LRN605/YA	922205	-	52	15
NF203	12203	17	40	12
NU203	32203	17	40	12	N305	2305	25	62	17
NJ203	42203	17	40	12	NU305	32305	25	62	17
RN203	502203	17	-	12	NJ305	42305	25	62	17
RNU203	292203	-	40	12	NUP305	92305	25	62	17
N204	2204	20	47	14	RN305	502305	25	-	17
NF204	12204	20	47	14	NF305	12305	25	62	17
NU204	32204	20	47	14	RNU305	292305	-	62	17
NJ204	42204	20	47	14	NCL2305	102605	25	62	24
NUP204	92204	20	47	14
RN204	502204	20	-	14	N206	2206	30	62	16
RNU204	292204	-	47	14	NF206	12206	30	62	16
RN-V604ENV/P6	E392704K	-	55	20	NU206	32206	30	62	16
					NJ206	42206	30	62	16
N304	2304	20	52	15	NUP206	92206	30	62	16
NF304	12304	20	52	15	RN206	502206	30	-	16
NU304	32304	20	52	15	RUN206	292206	-	62	16
NJ304	42304	20	52	15	NCL206	102206	30	62	16
NUP304	92304	20	52	15
RN304	502304	20	-	15	N306	2306	30	72	19
RNU304	292304	-	52	15	NF306	12306	30	72	19
					NU306	32306	30	72	19
N205	2205	25	52	15	NJ306	42306	30	72	19
NF205	12205	25	52	15	NUP306	92306	30	72	19
NU205	32205	25	52	15	RN306	502306	30	-	19
NJ205	42205	25	52	15

Roller Bearings Bearings Cylindrical Roller Bearing Non-Aligning Bearings

FAQ

Q YP Petro manufactures power end components including extension rods, crossheads, crosshead pins, cross pin baffles, upper and lower guide plates, packing boxes, seal rings, and oil seal lips. We also supply crankshaft assemblies, gear sets, and connecting rods for major mud pump models.

A
Yes. YP Petro accepts OEM/ODM orders based on customer drawings, technical specifications, or reverse-engineered samples. Our engineering team can confirm feasibility, recommend material upgrades, and provide quotations within 3-5 working days.
Q What power end parts does YP Petro manufacture?

A
YP Petro manufactures power end components including extension rods, crossheads, crosshead pins, cross pin baffles, upper and lower guide plates, packing boxes, seal rings, and oil seal lips. We also supply crankshaft assemblies, gear sets, and connecting rods for major mud pump models.
Q What other fluid end parts does YP Petro supply?

A
In addition to cylinder liners, YP Petro supplies a complete range of fluid end parts, including pistons, piston rubber, valve bodies, valve seats, valve rubber, liner seals, cylinder head gaskets, valve cover seals, piston rods, clamp assemblies, valve covers, cylinder heads, flange heads, cylinder flanges, cylinder covers, and inhalation capsules. We also supply dampener diaphragms, pressure gauges, fittings, relief valves, and exhaust valves.
Q What size range of cylinder liners does YP Petro offer?

A
YP Petro cylinder liners are available in metric sizes from 100mm to 180mm and imperial sizes from 3" to 7.5" (including 3", 3.5", 4", 4.5", 5", 5.5", 6", 6.25", 6.5", 6.75", 7", 7.25", 7.5"). Custom sizes are available on request.
Q What is the difference between bi-metal, ceramic, chrome-plated, and high-frequency quenching cylinder liners?

A
| Type | Inner Material | Hardness | Service Life | Best For |
| Bi-Metal | High-chromium cast iron | HRC 62 | 800h+ | General high-pressure, abrasive drilling |
| Ceramic | Al₂O₃ or Zirconia | HRC 80+ | 1500h+ | Extreme abrasion, high-sand formations |
| Chrome-Plated | Hard chrome coating | HRC 55 | 300-400h | Moderate conditions, budget operations |
| High-Frequency Quenching | Quenched alloy iron | HRC 50 | 200-300h | Light-duty, low-cost applications |
