Forged gate valve
Small size forged check valves are used below 2inch gate valve, design as per API602/BS5352 with forged materials, and is mainly used to small size pipeline for oil & gas, water treatment, power station and other fileds, to cut/on off medium in pipeline.
Technical Features :
Service | Oil, Gas, water treatment, power station and other pipeline. |
Design Body | Bolted bonnet/Pressure sealing bonnet/Welded bonnet |
Bore | Reduce bore/Full bore |
Design | Lift piston/ Swing type/ Ball type |
Size | 1/2”-2" |
Pressure | 150Lb-2500Lb |
Design temperature | -29-600℃ |
Main materials | A105/LF2/F304/F316/F51/F53/F51/F11/F22 |
Seat design | Integral seat |
Seat sealing material | 13Cr/Stellite |
Operation | Not applicable |
Design Standard | API602/S5352/DIN/GB/Ghost |
Face to face | ASME B16.10/Ghost /DIN/GB /Manufacture's standard |
Ends | RF/RTJ as ASME B16.5 , BW to ASME B16.25,SW to ASME B16.11 ,Thread ends as per ASME B16.11 |
Pressure and Temperature Design | ASME B16.34 |
Test standard | API598 |
Fire safe | APIF6A |
Others | NACE MR0175/ISO15156(if applicable) |
