Product Description
Model | ZS280-3P | ZS270-4P | ZS240-3P | ZS220-3P | ZS180-2P |
Motor power | 2×2.2 kW | 2×2.2 kW | 2×2.2 kW | 2×2.2 kW | 2×1.3 kW |
Screen area(m2) | 3×0.833×1.15 | 4×0.585×1.165 | 3×0.7×1.15 | 3×0.7×1.05 | 2×0.833×1.15 |
Shaking intensity（g） | 7.2 g | 7.2 g | 7.2 g | 7.2 g | 7.2 g |
Discharge capacity | 42 l/s | 40 l/s | 35 l/s | 30 l/s | 26 l/s |
Adjustable range | -2°～+6° | -2°～+6° | -2°～+6° | --2°～+6° | -2°～+6° |
Overall dimension,mm | 3140×1980×1540 | 2970×1980×1530 | 2700×1980×1540 | 2700×1900×1540 | 2300×1940×1300 |
Weight | 2000 kg | 2000kg | 1900kg | 1700 kg | 1200kg |
Model | ZS280-3P | ZS240-3P | ZS220-3P | ZS180-2P |
Motor power | 2×2.2 kW | 2×2.2 kW | 2×2.2 kW | 2×1.3 kW |
Screen area(m2) | 2.8 m2 | 2.4 m2 | 2.2 m2 | 1.8 m2 |
Shaking intensity（g） | 7.2 g | 7.2 g | 7.2 g | 7.2 g |
Discharge capacity | 42 l/s | 35 l/s | 30 l/s | 26 l/s |
Adjustable range | -2°～+6° | -2°～+6° | --2°～+6° | -2°～+6° |
Overall dimension,mm | 3140×1980×1540 | 2700×1980×1540 | 2700×1900×1540 | 2300×1940×1300 |
Weight | 2000 kg | 1900kg | 1700 kg | 1200kg |
