Features and advantages of FDLW series horizontal spiral decanter centrifuge:
1. Good sand removal effect. Combined with many years of experience in developing and producing centrifuges, and after a large number of field tests, we have optimized the parameters of the settling zone and the feeding method of the LW series centrifuges, which greatly enhances the desanding effect of the centrifuges, which can completely match the imported ones. Specifications comparable to centrifuges.
2. Low energy consumption and light workload. When the processing capacity is doubled, the power does not increase, and when the centrifuge is working at full load, the working load of the motor does not exceed 80% of the rated power.
3. Reliable work and long service life. The screw propeller, the key part of the centrifuge, is made of thick steel plate, and the thickness of the wear-resistant layer on the surface is twice as thick as the original one, which ensures the long life of the centrifuge. The main shaft adopts imported high-quality bearings, and the differential adopts high-precision hardened gear transmission. These measures make our centrifuge a very "skin" equipment, which is suitable for the harsh working conditions of the drilling site.
4. Low vibration and noise. By improving the machining accuracy and dynamic balance accuracy of the rotating part of the centrifuge, the vibration and noise of the centrifuge are reduced to an extremely low level.
Technical parameters of FDLW decanter decanter centrifuge
Technical Parameters | ||||||
| model | LW450-842 | LW450-842/NC | LW450-1000 | FDLW450-1250N | LW450-1670 | LW450-1820 |
Maximum capacity (m³/h) | 40 | 45 | 60 | 60 | 60 | 80 |
Minimum separation point (μm) | 5~7 | 2~3 | 5~7 | 3~5 | 3~5 | 2~5 |
Speed (rpm) | 2200 | 3900 | 1800 | 3200 | 3200 | 3200 |
separation factor | 1219 | 3832 | 1219 | 1575 | 2580 | 2580 |
Host power (kw) | 18.5 | 30 | 37 | 37 | 55 | 55 |
Auxiliary power (kw) | 5.5 | 11 | 7.5 | 7.5 | 18.5 | 18.5 |
Dimensions (mm) | 2470x1590x1515 | 2670x1450x1700 | 2470x1590x1515 | 2767x1697x1515 | 3630x1850x1380 | 3400x1455x1938 |
Host net weight (kg) | 1960KG | 2900KG | 2100KG | 2525KG | 4500 | 5200 |
