Home » Products » Drilling Rig Mud Circulation System » Solid Control Equipment » Vacuum Degasser » Horizontal Vacuum Degasser for Oilfield

PRODUCT CATEGORY

Horizontal Vacuum Degasser for Oilfield

Model:
all
Brand:
hebei yingpai
Code:
84139100


SKU:
Availability:



Inquire PDF Export

Product Description

Product Description

Horizontal Vacuum Degasser for Oilfield

SPECIFICATION:

Model	Working Volume	Max. Flow-rate (Liter/hr)			Total power
	(liter)	light liquid (<300cPs)	viscous product (<5,000cPs)	highly viscous product (≥5,000cPs)	(kW) (*)
PDA-25	25	1500	900	300	2.6
PDA-65	65	4000	2500	800	5.2
PDA-125	125	8000	5000	1600	8.9
PDA-300	300	15000	9000	3000	16.7
PDA-550	550	20000	12500	4000	28
PDA-1200	1200	30000	18000	6000	40.5

Model	L	W	H	H1, with open lid	Weight
	(mm)	(mm)	(mm)	(mm)	(kg)
PDA-25	1640	550	1650	1750	470
PDA-65	1855	715	1780	2200	690
PDA-125	2165	850	2170	2500	920
PDA-300	2455	1080	2590	3000	1300
PDA-550	2845	1225	2865	3300	1550
PDA-1200	3455	1850	3675	4180	2180

1) Total power (kW) (*) includes all the motors of the machine, e.g. distribution disc, vacuum pump, discharge pump, etc. 2) All specifications and illustrations are as accurate as is reasonably possible, but they are not binding. 3) PerMix reserves the right to modify the design without notice.

APPLICATIONS:

PerMix PDA series Vacuum Deaerators can be used extensively in many applications including but not limited to: - Foods Baby Food, Chocolate Fillings, Chocolate Frostings, Creams, Dessert Toppings, Fruit Concentrates, Ketchup, Mayonnaise, Mustard Paste, Salad Dressings, Sauces - Chemicals Adhesives, Glues, Ink Dispersions, Detergents, Plastics, Slurries, Oils, Paint Dispersions, Varnishes - Pharma & Cosmetics Creams, Emulsions, Gels, Lotions, Ointments, Shampoo, Toothpaste

Vacuum Degasser Full Automatic Vacuum Degasser Vacuum Degasser For Sale Vacuum Degasser Machine

FAQ

Q YP Petro manufactures power end components including extension rods, crossheads, crosshead pins, cross pin baffles, upper and lower guide plates, packing boxes, seal rings, and oil seal lips. We also supply crankshaft assemblies, gear sets, and connecting rods for major mud pump models.

A
Yes. YP Petro accepts OEM/ODM orders based on customer drawings, technical specifications, or reverse-engineered samples. Our engineering team can confirm feasibility, recommend material upgrades, and provide quotations within 3-5 working days.
Q What power end parts does YP Petro manufacture?

A
YP Petro manufactures power end components including extension rods, crossheads, crosshead pins, cross pin baffles, upper and lower guide plates, packing boxes, seal rings, and oil seal lips. We also supply crankshaft assemblies, gear sets, and connecting rods for major mud pump models.
Q What other fluid end parts does YP Petro supply?

A
In addition to cylinder liners, YP Petro supplies a complete range of fluid end parts, including pistons, piston rubber, valve bodies, valve seats, valve rubber, liner seals, cylinder head gaskets, valve cover seals, piston rods, clamp assemblies, valve covers, cylinder heads, flange heads, cylinder flanges, cylinder covers, and inhalation capsules. We also supply dampener diaphragms, pressure gauges, fittings, relief valves, and exhaust valves.
Q What size range of cylinder liners does YP Petro offer?

A
YP Petro cylinder liners are available in metric sizes from 100mm to 180mm and imperial sizes from 3" to 7.5" (including 3", 3.5", 4", 4.5", 5", 5.5", 6", 6.25", 6.5", 6.75", 7", 7.25", 7.5"). Custom sizes are available on request.
Q What is the difference between bi-metal, ceramic, chrome-plated, and high-frequency quenching cylinder liners?

A
| Type | Inner Material | Hardness | Service Life | Best For |
| Bi-Metal | High-chromium cast iron | HRC 62 | 800h+ | General high-pressure, abrasive drilling |
| Ceramic | Al₂O₃ or Zirconia | HRC 80+ | 1500h+ | Extreme abrasion, high-sand formations |
| Chrome-Plated | Hard chrome coating | HRC 55 | 300-400h | Moderate conditions, budget operations |
| High-Frequency Quenching | Quenched alloy iron | HRC 50 | 200-300h | Light-duty, low-cost applications |
