Home » Products » Drilling rig accessory equipment » Valve » Check valve » API Spec 6A Wellhead Stainless Steel Swing One Way Check Valve

PRODUCT CATEGORY

API Spec 6A Wellhead Stainless Steel Swing One Way Check Valve

API Spec 6A Wellhead Stainless Steel Swing One Way Check Valve

Model:
all
Brand:
hebei yingpai
Code:
84139100


SKU:
Availability:



Inquire PDF Export

Product Description

Product Description

API Spec 6A Wellhead Stainless Steel Swing One Way Check Valve

Technical Parameters

Product Name	Check Valve
Working Pressure	2000 psi~15000 psi
Nominal Bore	1 13/16"~7 1/16"
Temperature Level	K, L, P, R, S, T, U
Working Medium	oil, Nature gas, mud
Material	AISI 4130 (Integral Forged)
Body Material	Carbon Steel, Stainless Steel
Material Class	AA, BB, CC, DD, EE, FF
End Connection	API 6A Flange
Standards	API 6A, API 16C NACE-MR0175
Product Specification Level	PSL 1~PSL 4
Performance Requirement	PR 1~PR 2
Paint Color	Red or Customized
Application	Mud Choke Manifold Kill Manifold Wellhead Christmas Tree Connection

Product Description

Check valve creates the metal-to-metal seal by the pressure of the medium, the more the pressure is, the better the sealing effect is. Anytime the valve chamber can bear the pressure of the pipeline. The sealing face between valve core and valve body is welded with hard alloy with good abrasion resistance and anti-scour, the valve core is made of sulfide-resistance steel and the others adopts the process of hardness limit so the valve is able to be used in H₂S condition.

Features

(1). Sealing is energized by flow fluid pressure, sealing performance gets better while pressure increasing.

(2). Hard-faced sealing surface and sulfur-resistant core material assure fine performance of wear-resistant and corrosion-resistant.

(3). Integral forged body with fine mechanical properties.

(4). Check valve shall be hydro tested prior to delivery for sale performance.

Swing Check Valve One Way Check Valve Stainless Steel Check Valve

FAQ

Q YP Petro manufactures power end components including extension rods, crossheads, crosshead pins, cross pin baffles, upper and lower guide plates, packing boxes, seal rings, and oil seal lips. We also supply crankshaft assemblies, gear sets, and connecting rods for major mud pump models.

A
Yes. YP Petro accepts OEM/ODM orders based on customer drawings, technical specifications, or reverse-engineered samples. Our engineering team can confirm feasibility, recommend material upgrades, and provide quotations within 3-5 working days.
Q What power end parts does YP Petro manufacture?

A
YP Petro manufactures power end components including extension rods, crossheads, crosshead pins, cross pin baffles, upper and lower guide plates, packing boxes, seal rings, and oil seal lips. We also supply crankshaft assemblies, gear sets, and connecting rods for major mud pump models.
Q What other fluid end parts does YP Petro supply?

A
In addition to cylinder liners, YP Petro supplies a complete range of fluid end parts, including pistons, piston rubber, valve bodies, valve seats, valve rubber, liner seals, cylinder head gaskets, valve cover seals, piston rods, clamp assemblies, valve covers, cylinder heads, flange heads, cylinder flanges, cylinder covers, and inhalation capsules. We also supply dampener diaphragms, pressure gauges, fittings, relief valves, and exhaust valves.
Q What size range of cylinder liners does YP Petro offer?

A
YP Petro cylinder liners are available in metric sizes from 100mm to 180mm and imperial sizes from 3" to 7.5" (including 3", 3.5", 4", 4.5", 5", 5.5", 6", 6.25", 6.5", 6.75", 7", 7.25", 7.5"). Custom sizes are available on request.
Q What is the difference between bi-metal, ceramic, chrome-plated, and high-frequency quenching cylinder liners?

A
| Type | Inner Material | Hardness | Service Life | Best For |
| Bi-Metal | High-chromium cast iron | HRC 62 | 800h+ | General high-pressure, abrasive drilling |
| Ceramic | Al₂O₃ or Zirconia | HRC 80+ | 1500h+ | Extreme abrasion, high-sand formations |
| Chrome-Plated | Hard chrome coating | HRC 55 | 300-400h | Moderate conditions, budget operations |
| High-Frequency Quenching | Quenched alloy iron | HRC 50 | 200-300h | Light-duty, low-cost applications |
